系列	封装尺寸 (mm)	频率 (MHz)	频差 (ppm)	工作温度 (℃)
Model 575OscVCTCXO	7x5mm	10 – 36 MHz	±0.5 ppm to ±5 ppm	–40°C to +85°C +2.8Vdc~,+5.0Vdc
Model 353HCMOS VCXO	5.0mm x 3.2mm6-Pad	1 – 80 MHz	±50 PPM	-40°C to +85°C +2.5Vdc, +3.3Vdc or +5.0Vdc
Model 357HCMOSVCXO	7x5mm	1.5 – 77.76 MHz	±50 ppm	–40°C to +85°C +3.3Vdc or +5.0Vdc
Model 402	2.0mm x 1.6mm	16 – 60MHz	±20ppm	-40°C to +85°C
Model 403	3.2mm x 2.5mm	10 – 60MHz	±30ppm	-40°C to +85°C
Model 405	5.0mm x 3.2mm	6.76438 – 54MHz	±30ppm	-40°C to +85°C
Model 407	7.0mm x 5.0mm	6 – 133MHz	±30ppm	-40°C to +85°C
Model 416	1.6mm x 1.2mm	24 – 80MHz	±20ppm	-40°C to +85°C
Model 425	2.5mm x 2.0mm	12 – 60MHz	±20ppm	-40°C to +85°C
Model 443	3.2mm x 2.5mm	12 – 50 MHz	±20 ppm	-40°C to +85°C
Model 445	5.0mm x 3.2mm	8 – 50MHz	±20ppm	-40°C to +85°C
Model 520[VCTCXO]	2.5mmx2.0mm	10 – 52 MHz	±0.5ppm ~ ±2.5ppm	-40°C to +85°C +1.8Vdc ~ +2.5V
